Image Pick-up Device 　1/3" SHARP COLOR CCD
Horizontal Resolution 　420 TV Lines
Number of Pixels 　NTSC:510(H)×492(V); PAL:500(H)×582(V)
Scanning System 　NTSC:525 Lines,60 Field/sec,
PAL:625 Lines 50 Field/sec
Sync System 　Internal Synchronization
Gamma Characterlstic 　0.45
S/N Ratio 　≥48dB(AGC Off)
Electronic Shutter Time 　On: NTSC 1/60~1/100,000Sec,PAL 1/50~1/100,000Sec;
Off: NTSC 1/60 Sec, PAL 1/50 Sec
Usable Illumination 　1 Lux(F:2.0),0 lux with built-in IR LED
IR projecct distance 　15 meters(18 Unit Infrared LED)
IR Status　 　Under 10 Lux by CDS
IR Power On 　CDS Auto Control
Lens 　Board Lens 3.6mm/F2.0(optional)　
Video Output 　1.0Vp-p 75 ohm
Gain Control(AGC) 　Auto
Cable 　BNC JACK
Water resistance 　IP66
Operation Temperature 　-10℃～+50℃ RH95% Max
Storage Temperature 　-20℃～+60℃ RH95% Max
Power Supply 　DC12V±10% 600mA
Dimension 　75(W)X45(D)X75(H)mm
Weight 　300g
